High-Precision V-groove Processing Machine



OVERVIEW
---------------------------------------------------------------------------------------------------------
◎Uses a high-precision, high-rigidity air spindle.

◎Equipped with high-rigidity V-V slideways, ensuring long service life and durability.

Application Description
--------------------------------------------------------------------------------------------------------
For grinding, grooving, and cutting hard and brittle materials such as quartz, crystal, glass, and ferrite.

Workpiece
--------------------------------------------------------------------------------------------------------
Optical communication application: 128channel VG grooving (V 60°, pitch 0.127 mm)

Machining Targets:
Single pitch error ±0.3µm ↓
Cumulative error ±0.5µm ↓
Depth error ±0.3µm ↓

Applications
----------------------------------------------------------------------------------------------------
V-Groove is a key enabling device for advanced computing power, making it an ideal solution for low-loss performance.

Specification
